Cámara

Sensor De Imagen : 1/2.9″ Progressive Scan CMOS
Max. Resolución : 1920 × 1080
Iluminación Mínima : Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Tiempo De Obturación : 1/3 s to 1/100,000 s
Día Y Noche : IR cut filter
Ajuste De Ángulo : Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

Lente

Lente : Varifocal lens, motorized lens, 2.8 to 12 mm
Focal Length & FOV : 2.8 to 12 mm, horizontal FOV 102.4° to 31.2°, vertical FOV 54.4° to 17.5°, diagonal FOV 121.8° to 35.7°
Montura Del Lente : Ø14
Iris Type : Fixed
Apertura : F1.6

Iluminador

Tipo De Luz Suplementaria : IR
Rango De Luz Suplementaria : Up to 50 m
Luz De Suplemento Inteligente : Yes
IR Wavelength ; 850 nm

Vídeo

Main Stream :
50 Hz: 25 fps (1920 × 1080, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Compresión De Video
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
Vídeo Bitrate : 32 Kbps to 8 Mbps
Tipo H.264 : Baseline Profile,Main Profile,High Profile
Tipo H.265 : Main Profile
Región De Interés (ROI) : 1 fixed region(s) for main stream

Audio

Compresión De Audio : -S: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
Velocidad De Bits De Audio : -S: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)
Frecuencia De Muestreo De Audio : -S: 8 kHz/16 kHz
Filtro De Ruido Ambiental : -S: Yes

Red

Protocolos : TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
Vista En Vivo Simultánea : Up to 6 channels
API : Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
Seguridad : Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
Usuario/Operador : Up to 32 users
3 user levels: administrator, operator, and user
Cliente : iVMS-4200,Hik-Connect
Navegador Web :
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+

Imagen

Configuración De Imagen : Rotate mode,s aturation,brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
Interruptor Día/Noche : Auto,Schedule,Day,Night
Wide Dynamic Range (WDR) : Digital WDR
Mejora De La Imagen : BLC,HLC,3D DNR

Interfaz

Ethernet Interface : 1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage : Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB

Audio
-S: 1 input(s) (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

-S: 1 output(s) (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Alarma : -S: 1 input, 1 output (max. 12 VDC, 30mA)
Reset Key : Yes

Evento

Evento Básico : Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
Linkage : Upload to FTP/memory card, notify surveillance center, send email, trigger recording, trigger capture, trigger alarm output (-S)

General

Alimentación : 12 VDC ± 25%, 0.9 A, max. 11 W,Ø5.5 mm coaxial power plug,
PoE: 802.3af, Class 3, 36 V to 57 V, 0.36 A to 0.23 A, max. 12.9 W

Material : Metal
Dimensión : Ø105 mm × 244.4 mm (Ø4.1 × 9.6\”)”

Dimensión Del Paquete : 315 mm × 137 mm × 141 mm (12.4″ × 5.4″ × 5.6″)
Weight : Approx. 720 g (1.6 lb.)
Con Peso Del Paquete : Approx. 1110 g (2.4 lb.)

Condiciones De Almacenaje : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Condiciones De Inicio Y Funcionamiento : -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Idioma : English, Ukrainian

Función General : Heartbeat,anti-banding,mirror,password protection,privacy mask, watermark

Certificaciones :
EMC :
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7

Seguridad :
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

Ambiente :
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006

Protección
IP67: IEC 60529-2013
