Procesador

LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors.
L3 cache varies with CPU
(Please refer “CPU Support List” for more information.)

Chipset

Intel® B760 Express Chipset

Memoria

1.- Support for DDR4 5333(O.C.)/ 5133(O.C.)/ 5000(O.C.)/ 4933(O.C.)/ 4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3666(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 3000/ 2933/ 2666/ 2400/ 2133 MT/s memory modules
2.- 4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
3.- Dual channel memory architecture
4.-Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
5.- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
6.-Support for Extreme Memory Profile (XMP) memory modules
(Please refer “Memory Support List” for more information.)

Gráficos Integrados

Integrated Graphics Processor-Intel® HD Graphics support:
1.- 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
* Support for HDMI 2.0 version and HDCP 2.3.
2.- 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz
* Support for DisplayPort 1.2 version and HDCP 2.3
(Graphics specifications may vary depending on CPU support.)

Audio

1.- Realtek® Audio CODEC
2.- High Definition Audio
3.- 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
4.- Support for S/PDIF Out

LAN

Realtek® GbE LAN chip (1 Gbps/100 Mbps)

Wireless Communication module

Realtek® Wi-Fi RTL8821CE
1.- WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band
2.- BLUETOOTH 4.2
3.- Support for 11ac wireless standard and up to 433 Mbps data rate
(Actual data rate may vary depending on environment and equipment.)

Puertos de Expansión

CPU:
1.- 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Chipset:
1.- 4 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1
(PCIEX1_1, PCIEX1_3~PCIEX1_5)

Interfaz de Almacenamiento

CPU:
1.- 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
1.- 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
2.- 4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices

USB

Chipset:
1.- 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support
2.- 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header
3.- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
4.- 2 x USB 3.2 Gen 1 ports available through the internal USB header
5.- 4 x USB 2.0/1.1 ports on the back panel
Chipset+2 USB 2.0 Hubs:
1.- 4 x USB 2.0/1.1 ports available through the internal USB headers

Conectores Internos de E/S

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x CPU fan/water cooling pump header
3 x system fan headers
1 x system fan/water cooling pump header
2 x addressable LED strip headers
2 x RGB LED strip headers
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB Type-C® header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Q-Flash Plus button
1 x reset button
1 x reset jumper
1 x Clear CMOS jumper

Conectores del Panel Trasero

1 x PS/2 keyboard/mouse port
2 x SMA antenna connectors (1T1R)
1 x USB Type-C® port, with USB 3.2 Gen 2×2 support
1 x USB 3.2 Gen 2 Type-A port (red)
4 x USB 2.0/1.1 ports
1 x HDMI port
1 x DisplayPort
1 x RJ-45 port
3 x audio jacks

Controlador de E/S

iTE® I/O Controller Chip

Monitorización H/W

Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

BIOS

1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Características Únicas

1.- Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
2.- Support for Q-Flash
3.- Support for Q-Flash Plus

Software Incluido

1.- Norton® Internet Security (OEM version)
2.- LAN bandwidth management software

Sistema Operativo

Support for Windows 11 64-bit
Support for Windows 10 64-bit

Diseño

ATX Form Factor; 30.5cm x 24.4cm
