Thinkpad Lenovo P16V G2 Ultra 7 155H 16Gb 1Tb Rtx 20 21KY000XCL
PERFORMANCE | |
Processor |
Intel® Core™ Ultra 7 155H, 16C (6P + 8E + 2LPE) / 22T, Max Turbo up to 4.8GHz, 24MB
|
AI PC Category |
AI-Ready Workstations
|
NPU |
Integrated Intel® AI Boost, up to 11 TOPS
|
Graphics |
NVIDIA® RTX 2000 Ada Generation 8GB GDDR6
|
Chipset |
Intel® SoC Platform
|
Memory |
1x 16GB SO-DIMM DDR5-5600 Non-ECC
|
Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable
|
Max Memory |
Up to 96GB (2x 48GB DDR5 SO-DIMM)
|
Storage |
1TB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0
|
Storage Support
The storage capacity supported is based on the test results with current Lenovo storage offerings.
|
Up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 4TB, 2TB each
|
Storage Slot |
Two M.2 2280 PCIe® 4.0 x4 slots
|
RAID Preset |
None
|
Card Reader |
SD Express 7.0 Card Reader
|
Audio Chip |
High Definition (HD) Audio, Realtek® ALC3287 codec
|
Speakers |
Stereo speakers, 2W x2, Dolby Audio™ Premium
|
Camera |
FHD 1080p with Privacy Shutter
|
Microphone |
2x, Array
|
Battery |
Integrated 90Wh
|
Power Adapter |
170W Slim Tip (3-pin)
|
DESIGN | |
Display |
16″ WUXGA (1920×1200) IPS 300nits Anti-glare, 45% NTSC
|
Touchscreen |
None
|
Color Calibration |
None
|
Keyboard |
Backlit, Spanish (LA)
|
Case Color |
Black
|
Case Material |
PC-ABS (Top), PC-ABS (Bottom)
|
Pen |
Pen Not Supported
|
Dimensions (WxDxH)
The system dimensions may vary depending on configurations.
|
365 x 262 x 24.66 mm (14.37 x 10.32 x 0.97 inches)
|
Weight
The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
|
Starting at 2.22 kg (4.90 lbs)
|
SOFTWARE | |
Operating System |
Windows® 11 Pro, Spanish
|
Bundled Software |
None
|
CONNECTIVITY | |
Ethernet |
100/1000M (RJ-45)
|
WLAN + Bluetooth
Wi-Fi 6E full features might be limited by country-level restrictions.
Wi-Fi 6E is only enabled on Windows 11 and operates as Wi-Fi 6 with Windows 10.
6GHz Wi-Fi 6E operation is dependent on the support of the operating system, routers/APs/Gateways that support Wi-Fi 6E, and the regional regulatory certifications & spectrum allocation.
Bluetooth 5.3 operation requires Windows 11. For more information please visit
General Bluetooth Support Information on Microsoft
.
|
Intel® Wi-Fi® 6E AX211, 802.11ax 2×2 + BT5.3
|
WWAN |
Non-WWAN
|
SIM Card |
None
|
NFC |
None
|
Standard Ports |
|
Optional Ports (configured) |
None
|
Docking |
Various docking solutions supported via Thunderbolt™ or USB-C®.
For more compatible docking solutions, please visit
Docking for ThinkPad® P16v Gen 2
|
SECURITY & PRIVACY | |
Smart Card Reader |
None
|
Security Chip |
Discrete TPM 2.0 Enabled
|
Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button
|
Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm
|
Other Security |
Camera privacy shutter (camera models)
|
MANAGEABILITY | |
System Management |
Non-vPro®
|
SERVICE | |
Base Warranty |
3-year, Onsite
|
Included Upgrade |
None
|
ACCESSORIES | |
Bundled Accessories |
None
|
CERTIFICATIONS | |
Green Certifications |
|
Mil-Spec Test |
MIL-STD-810H military test passed
|
ISV Certifications |
Please visit
ISV certifications for Lenovo® Workstations
|
