| Cámara |
|
| Sensor De Imagen |
1/3” Progressive Scan CMOS |
| Max. Resolución |
2560 × 1440 |
| Iluminación Mínima |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Tiempo De Obturación |
1/3 s to 1/100,000 s |
| Día Y Noche |
IR cut filter |
| Ajuste De Ángulo |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Lente |
|
| Lente |
Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV |
2.8 mm, horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° |
| |
4 mm, horizontal FOV 78°, vertical FOV 42°, diagonal FOV 93° |
| Montura Del Lente |
M12 |
| Iris Type |
Fixed |
| Apertura |
F1.6 |
| DORI |
|
| DORI |
2.8 mm, D: 63 m, O: 25 m, R: 12 m, I: 6 m |
| |
4 mm, D: 78 m, O: 31 m, R: 15 m, I: 7 m |
| Iluminador |
|
| Tipo De Luz Suplementaria |
IR, White Light |
| Rango De Luz Suplementaria |
Up to 30 m |
| Luz De Suplemento Inteligente |
Yes |
| IR Wavelength |
850 nm |
| Vídeo |
|
| Main Stream |
50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) |
| |
60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) |
| |
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
| Compresión De Video |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Vídeo Bitrate |
32 Kbps to 8 Mbps |
| Tipo H.264 |
Baseline Profile, Main Profile, High Profile |
| Tipo H.265 |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Región De Interés (ROI) |
1 fixed region for main stream |
| Audio |
|
| Tipo De Audio |
Mono sound |
| Filtro De Ruido Ambiental |
Yes |
| Frecuencia De Muestreo De Audio |
8 kHz/16 kHz |
| Compresión De Audio |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Velocidad De Bits De Audio |
64 Kbps (G.711 ulaw), 64 Kbps (G.711 alaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 32 to 160 Kbps (MP2L2), 16 to 64 Kbps (AAC-LC) |
| Red |
|
| Seguridad |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| Vista En Vivo Simultánea |
Up to 6 channels |
| API |
Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK |
| Protocolos |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Usuario/Operador |
Up to 32 users, 3 user levels: administrator, operator, and user |
| Cliente |
iVMS-4200, Hik-Connect |
| Navegador Web |
Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+ |
| Imagen |
|
| Wide Dynamic Range (WDR) |
120 dB |
| SNR |
≥ 52 dB |
| Interruptor Día/Noche |
Day, Night, Auto, Schedule |
| Mejora De La Imagen |
BLC, HLC, 3D DNR |
| Configuración De Imagen |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Máscara De Privacidad |
4 programmable polygon privacy masks |
| Interfaz |
|
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
-F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Micrófono Incorporado |
Yes |
| Reset Key |
-F: Yes |
| Evento |
|
| Evento Básico |
Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
| Linkage |
Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture |
| General |
|
| Alimentación |
12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W |
| Material |
Metal & Plastic |
| Dimensión |
Ø121.4 mm × 97.7 mm (Ø4.8” × 3.8”) |
| Dimensión Del Paquete |
150 mm × 150 mm × 141 mm (5.9” × 5.9” × 5.6”) |
| Peso |
Approx. 550 g (1.2 lb.) |
| Con Peso Del Paquete |
Approx. 800 g (1.8 lb.) |
| Condiciones De Almacenaje |
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
| Condiciones De Inicio Y Funcionamiento |
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
| Idioma |
English, Ukrainian |
| Función General |
Heartbeat, anti-banding, mirror, password protection, password reset via email |
| Certificaciones |
EMC: FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7 |
| Seguridad |
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
| Ambiente |
CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Protección |
IP67: IEC 60529-2013, IK08: IEC 62262:2002 |
