Asus Prime-H310M-E-R2-0 Matx Mb Prime H310M-E R2.0
SKU: 13663 | NÚMERO DE PARTE: PRIME-H310M-E-R2.0 | CONDICIÓN: NUEVO
Retiro en tienda
Contáctanos para saber fecha de reposición
DESPACHO A DOMICILIO No disponible para despacho(Ver otros destinos)
$68.110
Con Transferencia electrónica
$71.856
Con Tarjetas de Crédito/Débito
AGOTADO
Asus Prime-H310M-E-R2-0 Matx Mb Prime H310M-E R2.0
Características
Placa Madre Asus Prime H310M-E R2.0
Las tarjetas madre ASUS Prime Serie 300 proporcionan la base sólida necesaria para tu armado, además de la flexibilidad para actualizarla en un futuro. Hemos añadido todas las características de los procesadores Core™ Intel® de octava generación con diseño e ingeniería de ASUS, incluye ajuste automático del sistema y refrigeración integral como controles y audio inmersivo. Cuando armas tu equipo con una tarjeta madre ASUS Prime Serie 300, construyes de forma inteligente, fácil y asequible.
Creada para durar
Lideramos el mercado de tarjetas madre porque tenemos una filosofía de diseño única. Nuestros bancos de pruebas superan los estándares de la industria y los componentes de gama alta que empleamos protegen tu equipo contra todo tipo de eventualidades. La compatibilidad de nuestras tarjetas madre se contrasta con más de 1000 dispositivos y componentes, y cada modelo es sometido a una batería de estrictas pruebas que toma más de 8000 horas. Te garantizamos que nuestras tarjetas madre pueden usarse para cualquier aplicación y en cualquier entorno. Además, al escoger ASUS, te beneficias de la posibilidad de instalar una gran variedad de componentes avanzados.
Intel H310 chipset
Intel ® H310 es un diseño de chips individual que admite procesadores Intel® Core ™ LGA1151 de octava generación. Proporciona un rendimiento mejorado al utilizar enlaces punto a punto en serie, lo que permite un mayor ancho de banda y estabilidad. Además, el chipset H310 proporciona un máximo de cuatro puertos USB 3.1 Gen 1, cuatro puertos SATA de 6 Gbps, 10 Gbps en M.2 y soporte para PCIe 2.0. Intel H310 también es compatible con gráficos integrados, por lo que disfrutará de lo último en rendimiento de gráficos.
LISTA PARA LA 8ª GENERACIÓN DE PROCESADORES INTEL CORE LGA1151 (Versión de 2-DIMM)
Esta tarjeta madre soporta procesadores Intel® Core™ de 8ª generación en el socket LGA1151, con gráficos integrados, memoria y controladores PCI Express para admitir la salida gráfica integrada con chipsets dedicados, memoria DDR4 de dos canales (2-DIMM) y 16 PCI Express 3.0/2.0 carriles para un gran rendimiento.
Estabilidad DDR4 mejorada
ASUS OptiMem preserva la integridad de la señal de memoria mediante el enrutamiento de trazas de memoria y vías a la capa de PCB, nuestro diseño de T-Topology asegura la señalización alineada en el tiempo mediante el equilibrio de longitudes de traza entre ranuras de memoria. Estas mejoras permiten a las tarjetas madre TUF Gaming admitir una amplia gama de kits de memoria DIMM duales y cuádruples, al tiempo que le brindan a tu plataforma la estabilidad que necesita para hacer frente a cualquier tipo de carga de trabajo, ya sea que esté jugando o ejecutando aplicaciones intensivas.
Velocidad a bordo con M.2
Con ancho de banda x2 PCI Express® 2.0, M.2 admite velocidades de transferencia de datos de hasta 10 Gbps. Es la elección perfecta para un sistema operativo o unidad de aplicación, proporcionando un acceso rápido a los datos.
Conector del panel frontal USB 3.1 Gen 1
USB 3.1 Gen 1 está justo donde lo necesitas, con cuatro encabezados de supervelocidad para el panel frontal. Experimenta velocidades de transferencia de datos hasta 10 veces más rápidas que USB 2.0 con conectividad instantánea plug-and-play.
Completa tu inmersión con ASUS
Las tarjetas madre Prime Serie 300 superan las especificaciones de VR Ready. La etiqueta ASUS Beyond VR Ready significa que hemos contrastado la compatibilidad de este dispositivo con cantidad de componentes de alta gama para que, dispongas del máximo rendimiento en aplicaciones de productividad, gaming y entretenimiento. ASUS Beyond VR Ready es la distinción de ASUS que te ayuda a configurar el equipo de tus sueños con las máximas garantías.
Especificaciones
CPU
- Intel® Socket 1151 for 8th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
- Supports Intel® 14 nm CPU
- Supports Intel® Turbo Boost Technology 2.0
-
- The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
-
- Refer to www.asus.com for CPU support list
Chipset
- Intel® H310
Memoria
- 2 x DIMM, Max. 32GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
- Dual Channel Memory Architecture
- Supports Intel® Extreme Memory Profile (XMP)
-
- Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
-
- The maximum memory frequency supported varies by processor
- ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.
Gráfica
- Integrated Graphics Processor- Intel® HD Graphics support
- Multi-VGA output support : HDMI/D-Sub ports
- – Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
- – Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
- Maximum shared memory of 1024 MB (for iGPU exclusively)
- Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
Puertos de Expansión
- 1 x PCIe 3.0/2.0 x16 (x16 mode, gray)
- 2 x PCIe 2.0 x1
Almacenamiento
- Intel® H310 Chipset :
- 1 x M.2 Socket 3, , with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode)*1
- 4 x SATA 6Gb/s port(s), gray,
LAN
- Realtek® RTL8111H, 1 x Gigabit LAN
Audio
- Realtek® ALC887 8-Channel High Definition Audio CODEC
- – Supports : Jack-detection, Front Panel Jack-retasking
- Audio Feature :
- – LED-illuminated design – Brighten up your build with the gorgeous illuminated audio trace path.
- – Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- – Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- – Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
-
- Choose the chassis with HD audio module in front panel to support 8-channel audio output.
Puertos USB
- Intel® H310 Chipset :
- 4 x USB 3.1 Gen 1 up to 5Gbps port(s) (2 at back panel, blue, Type-A, 2 at mid-board)
- Intel® H310 Chipset :
- 6 x USB 2.0/1.1 port(s) (2 at back panel, , 4 at mid-board)
Capacidades Especiales
- ASUS 5X Protection III :
- – ASUS SafeSlot Core: Fortified PCIe Slot prevents damage
- – ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!
- – ASUS Overvoltage Protection: World-class circuit-protecting power design
- – ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!
- – ASUS DIGI+ VRM: Premium components provide better power efficiency
- ASUS OptiMem?
- – Optimem (Improved DDR4 stability)
- ASUS EPU :
- – EPU
- ASUS Exclusive Features :
- – AI Suite 3
- – Ai Charger
- – PC Cleaner
- – File Transfer
- ASUS Quiet Thermal Solution :
- – Stylish Fanless Design Heat-sink solution
- – ASUS Fan Xpert
- ASUS EZ DIY :
- – ASUS CrashFree BIOS 3
- – ASUS EZ Flash 3
- – ASUS UEFI BIOS EZ Mode
- ASUS Q-Design :
- – ASUS Q-DIMM
- M.2 Onboard(The latest transfer technologies with up to 10Gb/s data transfer speeds)
Puertos posteriores I/O
- 1 x PS/2 keyboard (purple)
- 1 x PS/2 mouse (green)
- 1 x D-Sub
- 1 x HDMI
- 1 x LAN (RJ45) port(s)
- 2 x USB 3.1 Gen 1 (blue) Type-A up to 5Gbps
- 2 x USB 2.0
- 3 x Audio jack(s)
Internal I/O
- 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
- 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (both SATA & x2 PCIE mode)
- 1 x TPM header
- 1 x COM port(s) connector(s)
- 4 x SATA 6Gb/s connector(s)
- 1 x CPU Fan connector(s) (1 x 4 -pin)
- 1 x Chassis Fan connector(s) (1 x 4 -pin)
- 1 x S/PDIF out header(s)
- 1 x 24-pin EATX Power connector(s)
- 1 x 4-pin ATX 12V Power connector(s)
- 1 x Front panel audio connector(s) (AAFP)
- 1 x Clear CMOS jumper(s)
- 1 x System panel connector
- 1 x Speaker connector
Accesorios
- Users manual
- I/O Shield
- 2 x SATA 6Gb/s cable(s)
- 1 x M.2 Anchor
- 1 x Supporting DVD
BIOS
- 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, MultilanguageBIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 MyFavorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (SerialPresence Detect) memory information
Manejo
- WOL by PME, PXE
Sistema operativo
- Windows® 10 64-bit
Form Factor
- Micro ATX Form Factor
- 8.9 inch x 7.3 inch ( 22.6 cm x 18.5 cm )
Nota
- *1 When a device in SATA mode is installed on the M.2 socket, SATA_2 port cannot be used.
- Due to the Chipset limitation, when a M.2 device is installed in PCIe mode, the socket is set
- to PCIe 2.0.
